Instruction Video:

Installation instructions Wood screw TFT External

Wood screw TFT (external)

  • Function: Jetting screws TFT External is a wood screw with countersunk head. The unique tightening features of the screw have been achieved by providing the screw with a cutting drill tip, deeper thread and head than normal wood screws, as well as with oblique and longitudinal flanks between the threads. This provides the following benefits:
    • Less risk of cracks in wood.
    • Lower torque when tightening.
    • Less screwing time.
  • Track type bit: TX 15, 20, 25, 30 and 40.
  • Material: Case hardened steel.
  • Coating: Zincotech Au, corrosivity class C4, for outdoor use.
Unit Guide
D Diameter
D1 Outer diameter
G Thread length
H Head diameter
L Length
M Thickness
MB Mother box
Drill cap. mm Drill capacity mm
Max comp. thick. app. mm Max component thickness application mm
Min. drill depth mm Minimum drill depth mm
Screw dim. mm Screw dimension mm
Surface treat. Surface treatment
D L H G Bits/Socket Art.no E-number Quantity Pack. MB
* 3.5 20 7 20 15 P4703520 300 Plastic box 16
* 3.5 20 7 20 15 4703520 200 Packaging 16
* 3.5 20 7 20 15 SB4703520 45 Pack 10
* 3.5 30 7 18 15 P4703530 300 Plastic box 16
* 3.5 30 7 18 15 4703530 200 Packaging 16
* 3.5 30 7 18 15 SB4703530 40 Pack 10
* 3.5 40 7 24 15 P4703540 200 Plastic box 16
* 3.5 40 7 24 15 4703540 200 Packaging 16
* 3.5 40 7 24 15 SB4703540 35 Pack 10
4 25 8 18 20 P4704025 300 Plastic box 16
4 25 8 18 20 4704025 200 Packaging 16
4 25 8 18 20 SB4704025 40 Pack 10
4 30 8 18 20 P4704030 300 Plastic box 16
4 30 8 18 20 4704030 200 Packaging 16
4 30 8 18 20 SB4704030 35 Pack 10
4 35 8 24 20 P4704035 200 Plastic box 16
4 35 8 24 20 4704035 200 Packaging 16
4 35 8 24 20 SB4704035 30 Pack 10
4 40 8 24 20 P4704040 200 Plastic box 16
4 40 8 24 20 4704040 200 Packaging 16
4 40 8 24 20 SB4704040 30 Pack 10
4 50 8 30 20 P4704050 200 Plastic box 12
4 50 8 30 20 4704050 200 Packaging 12
4 50 8 30 20 SB4704050 20 Pack 10
4.5 30 9 18 25 P4704530 200 Plastic box 16
4.5 30 9 18 25 4704530 200 Packaging 16
4.5 30 9 18 25 SB4704530 25 Pack 10
4.5 40 9 24 25 P4704540 200 Plastic box 12
4.5 40 9 24 25 4704540 200 Packaging 16
4.5 40 9 24 25 SB4704540 20 Pack 10
4.5 50 9 30 25 P4704550 200 Plastic box 12
4.5 50 9 30 25 4704550 200 Packaging 12
4.5 50 9 30 25 SB4704550 15 Pack 10
4.5 60 9 36 25 P4704560 150 Plastic box 12
4.5 60 9 36 25 4704560 100 Packaging 16
4.5 60 9 36 25 SB4704560 10 Pack 10
4.5 70 9 42 25 P4704570 150 Plastic box 12
4.5 70 9 42 25 4704570 100 Packaging 16
4.5 70 9 42 25 SB4704570 10 Pack 10
4.5 80 9 42 25 P4704580 100 Plastic box 12
4.5 80 9 42 25 4704580 100 Packaging 12
4.5 80 9 42 25 SB4704580 10 Pack 10
5 40 10 24 25 P4705040 200 Plastic box 12
5 40 10 24 25 4705040 200 Packaging 12
5 40 10 24 25 SB4705040 15 Pack 10
5 50 10 30 25 4705050 200 Packaging 12
5 50 10 30 25 P4705050 150 Plastic box 12
5 50 10 30 25 SB4705050 15 Pack 10
5 60 10 36 25 P4705060 150 Plastic box 12
5 60 10 36 25 4705060 100 Packaging 16
5 60 10 36 25 SB4705060 10 Pack 10
5 70 10 42 25 A4705071 700 Large box
5 70 10 42 25 H4705070 700 Tub
5 70 10 42 25 P4705070 150 Plastic box 12
5 70 10 42 25 4705070 100 Packaging 16
5 70 10 42 25 SB4705070 10 Pack 10
5 80 10 42 25 A4705081 600 Large box
5 80 10 42 25 H4705080 500 Tub
5 80 10 42 25 P4705080 100 Plastic box 12
5 80 10 42 25 4705080 100 Packaging 12
5 80 10 42 25 SB4705080 9 Pack 10
5 85 10 42 25 P4705085 100 Plastic box 12
5 85 10 42 25 4705085 100 Packaging 12
5 90 10 42 25 A4705090 500 Large box
5 90 10 42 25 H4705090 500 Tub
5 90 10 42 25 P4705090 100 Plastic box 12
5 90 10 42 25 4705090 100 Packaging 12
5 90 10 42 25 SB4705090 8 Pack 10
5 100 10 54 25 H47050100 450 Tub
5 100 10 54 25 A47050100 450 Large box
5 100 10 54 25 P47050100 100 Plastic box 8
5 100 10 54 25 47050100 100 Packaging 8
5 100 10 54 25 SB47050100 7 Pack 10
5 120 10 72 25 H47050120 400 Tub
5 120 10 72 25 A47050120 400 Large box
5 120 10 72 25 P47050120 100 Plastic box 8
5 120 10 72 25 47050120 100 Packaging 8
5 120 10 72 25 SB47050120 6 Pack 10
6 60 12 36 30 P4706060 100 Plastic box 12
6 60 12 36 30 4706060 100 Packaging 12
6 60 12 36 30 SB4706060 8 Pack 10
6 70 12 42 30 P4706070 100 Plastic box 12
6 70 12 42 30 4706070 100 Packaging 12
6 70 12 42 30 SB4706070 7 Pack 10
6 80 12 42 30 A4706080 450 Large box
6 80 12 42 30 H4706080 450 Tub
6 80 12 42 30 P4706080 100 Plastic box 12
6 80 12 42 30 4706080 100 Packaging 12
6 80 12 42 30 SB4706080 6 Pack 10
6 85 12 42 30 P4706085 100 Plastic box 12
6 85 12 42 30 4706085 100 Packaging 12
6 90 12 42 30 A4706090 400 Large box
6 90 12 42 30 H4706090 350 Tub
6 90 12 42 30 P4706090 100 Plastic box 12
6 90 12 42 30 4706090 100 Packaging 12
6 90 12 42 30 SB4706090 5 Pack 10
6 100 12 54 30 A47060100 350 Large box
6 100 12 54 30 H47060100 350 Tub
6 100 12 54 30 P47060100 100 Plastic box 8
6 100 12 54 30 47060100 100 Packaging 8
6 100 12 54 30 SB47060100 4 Pack 10
6 110 12 60 30 P47060110 100 Plastic box 8
6 110 12 60 30 47060110 100 Packaging 8
6 120 12 72 30 A47060120 300 Large box
6 120 12 72 30 H47060120 300 Tub
6 120 12 72 30 P47060120 100 Plastic box 8
6 120 12 72 30 47060120 100 Packaging 8
6 120 12 72 30 SB47060120 4 Pack 10
6 130 12 72 30 P47060130 100 Plastic box 8
6 130 12 72 30 47060130 100 Packaging 8
6 140 12 72 30 P47060140 100 Plastic box 8
6 140 12 72 30 47060140 100 Packaging 8
6 140 12 72 30 SB47060140 3 Pack 10
6 150 12 72 30 47060150 100 Packaging 6
6 160 12 72 30 47060160 100 Packaging 6
6 160 12 72 30 SB47060160 2 Pack 10
6 180 12 72 30 47060180 100 Packaging 6
8 90 14.5 54 40 4708090 50 Packaging 12
8 120 14.5 72 40 47080120 50 Packaging 8
8 150 14.5 80 40 47080150 50 Packaging 6
8 180 14.5 80 40 47080180 25 Packaging 6
8 200 14.5 80 40 47080200 25 Packaging 6
8 240 14.5 80 40 47080240 25 Packaging 4
8 280 14.5 80 40 47080280 25 Packaging 4
8 320 14.5 80 40 47080320 25 Packaging 4
8 360 14.5 80 40 47080360 25 Packaging 4
*CE 14592 does not apply to this dimension. NOTE: Packs are only sold in multiples of ten.
